| Model | BL-1515 | BL-1515 MAX |
| 光管类型(Tube type) | 封闭式(Enclosed type) | 封闭式(Enclosed type) |
| 空间分辩率(Spatial resolution) | 100μm | 100μm |
| 光管电压(Tube voltage) | 80kv | 80kv |
| 光管电流(Tube current) | 0.6mA | 0.6mA |
| 取像方式(mage taking type) | 平板数字成像(Flat-panel Digital） | 平板数字成像(Flat-panel Digital） |
| 成像精度(Imaging precision) | 18.5μm | 18.5μm |
| A/D密度值(A/D density value) | 16bit(65536) | 16bit(65536) |
| 分辨率(Resolution) | 1400*1400px | 1400*1400px |
| 采集帧频(Frame frequency) | 2(FPS) | 10(FPS) |
| 光学放大(optical magnification) | 2X | 2X |
| 操作系统(Operating system) | WINDOWS 10/11 | WINDOWS 10/11 |
| 电源/功率(Power supply/Power) | AC110-220V 50-60HZ 1800W | AC110-220V 50-60HZ 1800W |
| 辐射安全测试(Radiation safety test) | <1 uSV/H | <1 uSV/H |
| 载物台旋转角度(Stage rotation angle) | NO | NO |
| 平板旋转角度(Detector rotation angle) | NO | NO |
| 载物台尺寸(Stage size) | 150*150mm | 150*150mm |
| 检测范围(Detection range) | 150*150mm | 150*150mm |
| 载物台承重(Load-bearing) | ≤2kg | ≤2kg |
| 机器尺寸(Machine size) | 505*700*800mm(L*WΛH) | 505*700*800mm(L"W"H) |
| 机器尺寸(含显示器)(lncluding monitor) | 505*700*800mm(L*W"H) | 505*700*800mm(L"W"H) |
| 机器重量(Machine weight) | 150kg | 150kg |
| 平台运动方式(Stage movement) | 自动/手动(Automatic/Manual) | 自动/手动(Automatic/Manual) |
| CE认证 (CE Certificate) | Yes | Yes |
| 辐射安全许可证(Radiation Safety Permit) | Yes | Yes |
